LCMA50-12F-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT RING 50MM #M12
PDF
/
Inventory: 2218
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Technical
Packaging Bulk
Published 2013
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
Contact Finish Tin
Wire Gauge 50mm2
Insulation Non-Insulated
Terminal Type Ring, Tubular
Stud/Tab Size M12 Stud
Terminal Style Single Stud Hole
Dimensions
Width - Outer Edges 0.906 23.01mm
Tab Thickness 0.071 1.80mm
Diameter - Barrel ID 0.386 (9.80mm)
Diameter - Barrel OD 0.484 (12.29mm)
Diameter - Ring ID 0.551 (14.00mm)
Compliance
RoHS Status ROHS3 Compliant
