LCMA300-16F-5

Panduit Corp
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description CONN TERM RECT RING 300MM #M16
PDF
/
Inventory: 3553
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Diameter - Ring ID 0.709 (18.01mm)
Diameter - Barrel OD 1.142 (29.01mm)
Diameter - Barrel ID 0.925 (23.50mm)
Tab Thickness 0.213 5.40mm
Width - Outer Edges 1.673 42.49mm

Technical

Terminal Style Single Stud Hole
Stud/Tab Size M16 Stud
Terminal Type Ring, Tubular
Insulation Non-Insulated
Wire Gauge 300mm2
Contact Finish Tin
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2013
Packaging Bulk

Physical

Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Plating Tin
Contact Material Copper

Supply Chain

Factory Lead Time 4 Weeks
