LCMA240-20F-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Pan-Lug? ROHS3Compliant 2013 Non-Insulated Terminal Rectangular Connector 0.819 (20.80mm)
PDF
/
Inventory: 7386
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Technical
Packaging Bulk
Published 2013
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
Contact Finish Tin
Wire Gauge 240mm2
Insulation Non-Insulated
Terminal Type Ring, Tubular
Stud/Tab Size M20 Stud
Terminal Style Single Stud Hole
Dimensions
Width - Outer Edges 1.476 37.49mm
Tab Thickness 0.205 5.21mm
Diameter - Barrel ID 0.819 (20.80mm)
Diameter - Barrel OD 1.024 (26.01mm)
Diameter - Ring ID 0.866 (22.00mm)
Compliance
RoHS Status ROHS3 Compliant
