LCMA16-5F-C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT RING 16MM #M5
PDF
/
Buying Options
Total Price: USD $1.63
Unit Price: USD $1.628
≥1 USD $1.628
Inventory: 61
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Diameter - Ring ID 0.217 (5.51mm)
Diameter - Barrel OD 0.283 (7.19mm)
Diameter - Barrel ID 0.217 (5.51mm)
Tab Thickness 0.065 1.65mm
Width - Outer Edges 0.512 13.00mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size M5 Stud
Terminal Type Ring, Tubular
Insulation Non-Insulated
Wire Gauge 16mm2
Contact Finish Tin
Termination Crimp, Flag
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2000
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
