LCMA16-10-C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Terminals Copper Comp Metric Lug, 1 Hole, 1
PDF
/
Buying Options
Total Price: USD $1.58
Unit Price: USD $1.5752
≥1 USD $1.5752
≥10 USD $1.53296
≥100 USD $1.4146
≥500 USD $1.296759
≥1000 USD $1.218166
Inventory: 164
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.433 (11.00mm)
Diameter - Barrel OD 0.283 (7.19mm)
Diameter - Barrel ID 0.217 (5.51mm)
Tab Thickness 0.043 1.09mm
Width - Outer Edges 0.591 15.00mm
Length - Overall 1.445 36.70mm
Length 36.703mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size M10 Stud
Wire Cross Section 16 mm2
Terminal Type Ring, Tubular
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 16 AWG
Wire Gauge 16mm2
Depth 15mm
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2014
Packaging Bulk
Physical
Weight 453.59237g
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
