LCMA150-8-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Terminals Copper Comp Metric Lug, 1 Hole, 1
PDF
/
Buying Options
Total Price: USD $17.49
Unit Price: USD $17.4856
≥1 USD $17.4856
≥10 USD $17.00336
≥100 USD $16.5176
≥500 USD $16.03184
≥1000 USD $15.545992
≥3000 USD $15.060144
Inventory: 77
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Weight 816.466266g
Technical
Packaging Bulk
Published 2011
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
HTS Code 8536.90.40.00
Depth 30.5mm
Wire Gauge 150mm2
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Ring, Tubular
Wire Cross Section 150 mm2
Stud/Tab Size M8 Stud
Terminal Style Single Stud Hole
Dimensions
Length 70.5104mm
Length - Overall 2.776 70.50mm
Width - Outer Edges 1.201 30.51mm
Tab Thickness 0.175 4.45mm
Diameter - Barrel ID 0.650 (16.51mm)
Diameter - Barrel OD 0.827 (21.01mm)
Diameter - Ring ID 0.354 (8.99mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
