LCMA120-12H-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT RING 120MM #M12
PDF
/
Inventory: 2126
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line), 45° Angle
Technical
Packaging Bulk
Published 2013
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
HTS Code 8536.90.40.00
Contact Finish Tin
Wire Gauge 120mm2
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Ring, Tubular
Stud/Tab Size M12 Stud
Terminal Style Single Stud Hole
Dimensions
Width - Outer Edges 1.083 27.51mm
Tab Thickness 0.138 3.51mm
Diameter - Barrel ID 0.598 (15.19mm)
Diameter - Barrel OD 0.732 (18.59mm)
Diameter - Ring ID 0.551 (14.00mm)
Compliance
RoHS Status ROHS3 Compliant
