LCMA10-8-C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Terminals Copper Comp Metric Lug, 1 Hole, 1
PDF
/
Buying Options
Total Price: USD $1.26
Unit Price: USD $1.2584
≥1 USD $1.2584
≥10 USD $1.22848
≥100 USD $1.134056
≥500 USD $1.039544
≥1000 USD $0.976536
Inventory: 151
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.354 (8.99mm)
Diameter - Barrel OD 0.244 (6.20mm)
Diameter - Barrel ID 0.177 (4.50mm)
Tab Thickness 0.041 1.05mm
Width - Outer Edges 0.512 13.00mm
Length - Overall 1.213 30.81mm
Length 30.8102mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size M8 Stud
Terminal Type Ring, Tubular
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 10 AWG
Wire Gauge 10mm2
Contact Finish Tin
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2005
Packaging Bulk
Physical
Weight 22.679619g
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
