LCMA10-6H-C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT RING 10MM #M6
PDF
/
Buying Options
Total Price: USD $1.16
Unit Price: USD $1.164542
≥1 USD $1.164542
Inventory: 3872
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Diameter - Ring ID 0.260 (6.60mm)
Diameter - Barrel OD 0.244 (6.20mm)
Diameter - Barrel ID 0.177 (4.50mm)
Tab Thickness 0.047 1.19mm
Width - Outer Edges 0.433 11.00mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size M6 Stud
Terminal Type Ring, Tubular
Insulation Non-Insulated
Wire Gauge 10mm2
Contact Finish Tin
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp, Flag
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2013
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line), 45° Angle
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
