LCDX650-12H-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT TONG 650 MCM #1/2
PDF
/
Inventory: 4475
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Diameter - Ring ID 0.530 (13.46mm)
Diameter - Barrel OD 1.350 (34.29mm)
Diameter - Barrel ID 1.050 (26.67mm)
Tab Thickness 0.300 7.62mm
Width - Outer Edges 1.950 49.53mm
Technical
Terminal Style Two Stud Holes
Stud/Tab Size 1/2 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge 650MCM (kcmil)
Contact Finish Electro-Tin
HTS Code 8536.90.40.00
Color Black
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2011
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line), 45° Angle
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
