LCDX6-14AF-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 6AWG 42.2mm 12.2mm Tin
PDF
/
Buying Options
Total Price: USD $8.63
Unit Price: USD $8.6328
≥1 USD $8.6328
≥10 USD $8.3996
≥100 USD $7.699384
≥500 USD $7.232746
Inventory: 70
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.270 (6.86mm)
Diameter - Barrel OD 0.310 (7.87mm)
Diameter - Barrel ID 0.220 (5.59mm)
Tab Thickness 0.080 2.03mm
Width - Outer Edges 0.480 12.19mm
Length 42.2mm
Technical
Terminal Gender FEMALE
Terminal Style Two Stud Holes
Stud/Tab Size 1/4 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Wire/Cable Gauge 6 AWG
Body Plating Tin
Wire Gauge 6 AWG
Contact Finish Electro-Tin
Depth 12.2mm
HTS Code 8536.90.40.00
Color Blue
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
