LCDX4/0-14AF-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (4/0)AWG 57.9mm 30.2mm Tin
PDF
/
Inventory: 4792
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.270 (6.86mm)
Diameter - Barrel OD 0.810 (20.57mm)
Diameter - Barrel ID 0.650 (16.51mm)
Tab Thickness 0.160 4.06mm
Width - Outer Edges 1.190 30.23mm
Technical
Terminal Style Two Stud Holes
Stud/Tab Size 1/4 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Wire Gauge 4/0 AWG
Contact Finish Electro-Tin
Color Purple
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series Pan-Lug?
Published 2011
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
