LCDX350-12H-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (6.2/0)AWG 117.1mm 39.1mm Tin
PDF
/
Inventory: 5745
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line), 45° Angle
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Blue
HTS Code 8536.90.40.00
Depth 39.1mm
Contact Finish Electro-Tin
Wire Gauge 350MCM (kcmil)
Body Plating Tin
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 1/2 Stud
Terminal Style Two Stud Holes
Terminal Gender FEMALE
Dimensions
Width - Outer Edges 1.540 39.12mm
Tab Thickness 0.220 5.59mm
Diameter - Barrel ID 0.840 (21.34mm)
Diameter - Barrel OD 1.060 (26.92mm)
Diameter - Ring ID 0.530 (13.46mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
