LCDX250-38-X
RoHS
RoHS compliant
RoHS compliantPackage 104
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (4.7/0)AWG 104.9mm 32.5mm Tin
PDF
/
Buying Options
Total Price: USD $17.74
Unit Price: USD $17.7408
≥1 USD $17.7408
Inventory: 28
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.410 (10.41mm)
Diameter - Barrel OD 0.880 (22.35mm)
Diameter - Barrel ID 0.700 (17.78mm)
Tab Thickness 0.170 4.32mm
Width - Outer Edges 1.280 32.51mm
Length - Overall 4.120 104.65mm
Length 104.648mm
Technical
Terminal Gender FEMALE
Terminal Style Two Stud Holes
Stud/Tab Size 3/8 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Body Plating Tin
Wire Gauge 250MCM (kcmil)
Contact Finish Electro-Tin
Depth 32.5mm
HTS Code 8536.90.40.00
Color Yellow
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Package / Case 104
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
