LCDX1/0-12-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (1/0)AWG 102.9mm 21.6mm Tin
PDF
/
Buying Options
Total Price: USD $10.47
Unit Price: USD $10.472
≥1 USD $10.472
≥10 USD $10.18776
≥100 USD $9.904928
≥500 USD $9.62192
≥1000 USD $9.339
≥3000 USD $9.05601
Inventory: 100
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.530 (13.46mm)
Diameter - Barrel OD 0.580 (14.73mm)
Diameter - Barrel ID 0.450 (11.43mm)
Tab Thickness 0.130 3.30mm
Width - Outer Edges 0.850 21.59mm
Length - Overall 4.040 102.62mm
Length 102.616mm
Technical
Terminal Style Two Stud Holes
Stud/Tab Size 1/2 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Body Plating Tin
Wire Gauge 1/0 AWG
Contact Finish Electro-Tin
Depth 21.6mm
Color Pink
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2011
Packaging Bulk
Physical
Body Material Copper
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
