LCD4-38D-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 2AWG 72.4mm 15.7mm Tin
PDF
/
Buying Options
Total Price: USD $6.53
Unit Price: USD $6.5296
≥1 USD $6.5296
≥10 USD $6.35536
≥100 USD $5.825864
≥500 USD $5.472799
Inventory: 72
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.410 (10.41mm)
Diameter - Barrel OD 0.380 (9.65mm)
Diameter - Barrel ID 0.280 (7.11mm)
Tab Thickness 0.080 2.03mm
Width - Outer Edges 0.620 15.75mm
Length - Overall 2.850 72.40mm
Length 72.39mm
Technical
Terminal Style Two Stud Holes
Stud/Tab Size 3/8 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 2 AWG
Body Plating Tin
Wire Gauge 4 AWG
Contact Finish Electro-Tin
Depth 15.7mm
HTS Code 8536.90.40.00
Color Gray
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
