LCD4-14B-L

Panduit Corp
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description Lug Terminal 3AWG/4AWG 60.45mm 13.97mm Electro-Tin
PDF
/
Inventory: 1261
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Diameter - Ring ID 0.270 (6.86mm)
Diameter - Barrel OD 0.380 (9.65mm)
Diameter - Barrel ID 0.280 (7.11mm)
Tab Thickness 0.090 2.29mm
Width - Outer Edges 0.550 13.97mm
Length - Overall 2.380 60.45mm
Length 60.452mm

Technical

Terminal Style Two Stud Holes
Stud/Tab Size 1/4 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 4 AWG
Body Plating Tin
Wire Gauge (Min) 4 AWG
Wire Gauge (Max) 3 AWG
Wire Gauge 4 AWG
Contact Finish Electro-Tin
Depth 13.97mm
HTS Code 8536.90.40.00
Gender Male
Color Gray
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2004
Packaging Bulk

Physical

Weight 816.466266g
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper

Supply Chain

Factory Lead Time 4 Weeks
