LCD4/0-38DH-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (4/0)AWG 77.5mm 26.9mm Tin
PDF
/
Buying Options
Total Price: USD $52.55
Unit Price: USD $52.550135
≥1 USD $52.550135
≥200 USD $20.968326
≥500 USD $20.267237
≥1000 USD $19.921945
Inventory: 1970
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line), 45° Angle
Technical
Packaging Bulk
Published 2011
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Purple
HTS Code 8535.90.80.20
Depth 26.9mm
Contact Finish Electro-Tin
Wire Gauge 4/0 AWG
Body Plating Tin
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 3/8 Stud
Terminal Style Two Stud Holes
Terminal Gender FEMALE
Dimensions
Length 77.5mm
Width - Outer Edges 1.060 26.92mm
Tab Thickness 0.140 3.56mm
Diameter - Barrel ID 0.570 (14.48mm)
Diameter - Barrel OD 0.710 (18.03mm)
Diameter - Ring ID 0.410 (10.41mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
