LCD350-12E-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (6.2/0)AWG 110mm 32.5mm Tin
PDF
/
Inventory: 6287
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.530 (13.46mm)
Diameter - Barrel OD 0.880 (22.35mm)
Diameter - Barrel ID 0.700 (17.78mm)
Tab Thickness 0.170 4.32mm
Width - Outer Edges 1.280 32.51mm
Length - Overall 4.330 109.98mm
Length 109.982mm
Technical
Terminal Style Two Stud Holes
Stud/Tab Size 1/2 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Body Plating Tin
Wire Gauge 350MCM (kcmil)
Contact Finish Electro-Tin
Depth 32.5mm
HTS Code 8536.90.40.00
Color Red
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
