LCD3/0-12H-X
RoHS
RoHS compliant
RoHS compliantPackage 104
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (3/0)AWG 104.6mm 24.4mm Tin
PDF
/
Inventory: 3682
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.530 (13.46mm)
Diameter - Barrel OD 0.640 (16.26mm)
Diameter - Barrel ID 0.510 (12.95mm)
Tab Thickness 0.130 3.30mm
Width - Outer Edges 0.960 24.38mm
Length 104.6mm
Technical
Terminal Gender FEMALE
Terminal Style Two Stud Holes
Stud/Tab Size 1/2 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Body Plating Tin
Wire Gauge 3/0 AWG
Contact Finish Electro-Tin
Depth 24.4mm
HTS Code 8536.90.40.00
Color Orange
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Package / Case 104
Mounting Type Free Hanging (In-Line), 45° Angle
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
