LCD2-38DH-Q
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 2AWG 68.8mm 16.8mm Tin
PDF
/
Buying Options
Total Price: USD $8.78
Unit Price: USD $8.7824
≥1 USD $8.7824
Inventory: 87
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line), 45° Angle
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Brown
HTS Code 8536.90.40.00
Depth 16.8mm
Contact Finish Electro-Tin
Wire Gauge 2 AWG
Body Plating Tin
Wire/Cable Gauge 2 AWG
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 3/8 Stud
Terminal Style Two Stud Holes
Terminal Gender FEMALE
Dimensions
Length 68.8mm
Width - Outer Edges 0.660 16.76mm
Tab Thickness 0.100 2.54mm
Diameter - Barrel ID 0.310 (7.87mm)
Diameter - Barrel OD 0.420 (10.67mm)
Diameter - Ring ID 0.410 (10.41mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Alternative Model
