LCD1000-12UP-3
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Terminal Rectangular Connector
PDF
/
Inventory: 9128
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Diameter - Ring ID 0.530 (13.46mm)
Diameter - Barrel OD 1.500 (38.10mm)
Diameter - Barrel ID 1.170 (29.72mm)
Tab Thickness 0.320 8.13mm
Width - Outer Edges 2.170 55.12mm
Length - Overall 5.770 146.56mm
Length 146.558mm
Technical
Terminal Style Two Stud Holes
Stud/Tab Size 1/2 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Wire Gauge 1000MCM (kcmil)
Contact Finish Electro-Tin
Color White
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Series Pan-Lug?
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
