LCD10-14DF-L

Panduit Corp
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description Terminal Rectangular Connector
PDF
/
Inventory: 4163
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Diameter - Ring ID 0.270 (6.86mm)
Diameter - Barrel OD 0.220 (5.59mm)
Diameter - Barrel ID 0.130 (3.30mm)
Tab Thickness 0.050 1.27mm
Width - Outer Edges 0.420 10.67mm

Technical

Terminal Style Two Stud Holes
Stud/Tab Size 1/4 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Wire/Cable Gauge 10 AWG
Wire Gauge 10 AWG
Contact Finish Electro-Tin
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Packaging Bulk

Physical

Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Plating Tin
Contact Material Copper

Supply Chain

Factory Lead Time 4 Weeks
