LCD1-12F-E
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 1AWG 93.5mm 19mm Tin
PDF
/
Inventory: 6016
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.530 (13.46mm)
Diameter - Barrel OD 0.470 (11.94mm)
Diameter - Barrel ID 0.360 (9.14mm)
Tab Thickness 0.090 2.29mm
Width - Outer Edges 0.750 19.05mm
Length 93.5mm
Technical
Terminal Gender FEMALE
Terminal Style Two Stud Holes
Stud/Tab Size 1/2 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Wire/Cable Gauge 1 AWG
Body Plating Tin
Wire Gauge 1 AWG
Contact Finish Electro-Tin
Depth 19mm
HTS Code 8536.90.40.00
Color Green
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
