LCCX500-12-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (7.7/0)AWG 169.2mm 48mm Tin
PDF
/
Buying Options
Total Price: USD $47.66
Unit Price: USD $47.6608
≥1 USD $47.6608
≥10 USD $46.30208
≥100 USD $42.216592
Inventory: 66
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Pink
HTS Code 8536.90.40.00
Contact Finish Electro-Tin
Wire Gauge 500MCM (kcmil)
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 1/2 Stud
Terminal Style Two Stud Holes
Terminal Gender FEMALE
Dimensions
Length 169.164mm
Length - Overall 6.660 169.16mm
Width - Outer Edges 1.890 48.01mm
Tab Thickness 0.260 6.60mm
Diameter - Barrel ID 1.030 (26.16mm)
Diameter - Barrel OD 1.300 (33.02mm)
Diameter - Ring ID 0.530 (13.46mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
