LCCX250-38DF-X

Panduit Corp
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description Terminals COPPER COMPRESSION LUG 2 HOLE YLW
PDF
/
Inventory: 5458
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 3/8 Stud
Terminal Style Two Stud Holes
Terminal and Terminal Block Type WIRE TERMINAL
Wire Gauge 250MCM (kcmil)
Contact Finish Electro-Tin
HTS Code 8536.90.40.00
Gender Female
Color Yellow
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2004
Packaging Bulk

Dimensions

Length 74.676mm
Width - Outer Edges 1.280 32.51mm
Tab Thickness 0.170 4.32mm
Diameter - Barrel ID 0.700 (17.78mm)
Diameter - Barrel OD 0.880 (22.35mm)
Diameter - Ring ID 0.410 (10.41mm)

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant

Physical

Weight 1.638829kg
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Plating Tin
Contact Material Copper

Supply Chain

Factory Lead Time 4 Weeks
