LCCX250-12-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (4.7/0)AWG 146.6mm 32.5mm Tin
PDF
/
Buying Options
Total Price: USD $20.39
Unit Price: USD $20.3896
≥1 USD $20.3896
≥10 USD $19.8264
≥100 USD $19.260032
≥500 USD $18.693488
≥1000 USD $18.127032
≥3000 USD $17.560541
Inventory: 43
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.530 (13.46mm)
Diameter - Barrel OD 0.880 (22.35mm)
Diameter - Barrel ID 0.700 (17.78mm)
Tab Thickness 0.170 4.32mm
Width - Outer Edges 1.280 32.51mm
Length - Overall 5.770 146.56mm
Length 146.558mm
Technical
Terminal Style Two Stud Holes
Stud/Tab Size 1/2 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Wire Gauge 250MCM (kcmil)
Contact Finish Electro-Tin
HTS Code 8536.90.40.00
Color Yellow
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2001
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
