LCCN750-12W-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (9.5/0)AWG 169.2mm 33mm Tin
PDF
/
Buying Options
Total Price: USD $53.13
Unit Price: USD $53.1344
≥1 USD $53.1344
Inventory: 69
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.530 (13.46mm)
Diameter - Barrel OD 1.300 (33.02mm)
Diameter - Barrel ID 1.030 (26.16mm)
Tab Thickness 0.280 7.11mm
Width - Outer Edges 1.300 33.02mm
Length - Overall 6.660 169.16mm
Length 169.164mm
Technical
Terminal Style Two Stud Holes
Stud/Tab Size 1/2 Stud
Wire Cross Section 484 mm2
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge 750MCM (kcmil)
Contact Finish Electro-Tin
HTS Code 8536.90.40.00
Color Black
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2005
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
