LCCF750-12H-3

Panduit Corp
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description Lug Terminal (9.5/0)AWG 162.3mm 55.1mm Tin
PDF
/
Inventory: 7917
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Diameter - Ring ID 0.530 (13.46mm)
Diameter - Barrel OD 1.800 (45.72mm)
Diameter - Barrel ID 1.170 (29.72mm)
Tab Thickness 0.320 8.13mm
Width - Outer Edges 2.170 55.12mm

Technical

Terminal Style Two Stud Holes
Stud/Tab Size 1/2 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Body Plating Tin
Wire Gauge 750MCM (kcmil)
Contact Finish Electro-Tin
Depth 55.1mm
HTS Code 8536.90.40.00
Color Orange
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2011
Packaging Bulk

Physical

Mounting Type Free Hanging (In-Line), 45° Angle
Mount Free Hanging
Contact Material Copper

Supply Chain

Factory Lead Time 4 Weeks
