LCCF4/0-38DF-X

Panduit Corp
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description Lug Terminal (4/0)AWG 75.4mm 29.7mm Tin
PDF
/
Inventory: 7978
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Diameter - Ring ID 0.410 (10.41mm)
Diameter - Barrel OD 0.910 (23.11mm)
Diameter - Barrel ID 0.630 (16.00mm)
Tab Thickness 0.140 3.56mm
Width - Outer Edges 1.170 29.72mm
Length 75.4mm

Technical

Terminal Style Two Stud Holes
Stud/Tab Size 3/8 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Body Plating Tin
Wire Gauge 4/0 AWG
Contact Finish Electro-Tin
Depth 29.7mm
HTS Code 8536.90.40.00
Color Yellow
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series Pan-Lug?
Published 2004
Packaging Bulk

Physical

Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Material Copper

Supply Chain

Factory Lead Time 4 Weeks
