LCCF4/0-12-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (4/0)AWG 132.8mm 29.7mm Tin
PDF
/
Buying Options
Total Price: USD $16.94
Unit Price: USD $16.94
≥1 USD $16.94
≥10 USD $16.46832
≥100 USD $15.998048
≥500 USD $15.527424
≥1000 USD $15.056976
≥3000 USD $14.58644
Inventory: 89
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Yellow
HTS Code 8536.90.40.00
Depth 29.7mm
Contact Finish Electro-Tin
Wire Gauge 4/0 AWG
Body Plating Tin
Terminal and Terminal Block Type RING TERMINAL
Safety Approval CSA; UL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 1/2 Stud
Terminal Style Two Stud Holes
Dimensions
Length 132.842mm
Length - Overall 5.230 132.84mm
Width - Outer Edges 1.170 29.72mm
Tab Thickness 0.140 3.56mm
Diameter - Barrel ID 0.630 (16.00mm)
Diameter - Barrel OD 0.910 (23.11mm)
Diameter - Ring ID 0.530 (13.46mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
