LCCF300-12H-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (5.5/0)AWG 137.9mm 35.1mm Tin
PDF
/
Inventory: 7740
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.530 (13.46mm)
Diameter - Barrel OD 1.100 (27.94mm)
Diameter - Barrel ID 0.760 (19.30mm)
Tab Thickness 0.180 4.57mm
Width - Outer Edges 1.380 35.05mm
Technical
Terminal Style Two Stud Holes
Stud/Tab Size 1/2 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Body Plating Tin
Wire Gauge 300MCM (kcmil)
Contact Finish Electro-Tin
Depth 35.1mm
Color Red
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Body Material Copper
Mounting Type Free Hanging (In-Line), 45° Angle
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
