LCCF2-14BF-E

Panduit Corp
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description Lug Terminal 2AWG 53.3mm 17.8mm Tin
PDF
/
Inventory: 8012
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Diameter - Ring ID 0.270 (6.86mm)
Diameter - Barrel OD 0.550 (13.97mm)
Diameter - Barrel ID 0.360 (9.14mm)
Tab Thickness 0.110 2.79mm
Width - Outer Edges 0.700 17.78mm
Length 53.3mm

Technical

Terminal Style Two Stud Holes
Stud/Tab Size 1/4 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Wire/Cable Gauge 2 AWG
Body Plating Tin
Wire Gauge 2 AWG
Contact Finish Electro-Tin
Depth 17.8mm
HTS Code 8536.90.40.00
Color Brown
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Pbfree Code yes
Series Pan-Lug?
Published 2004
Packaging Bulk

Physical

Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Material Copper

Supply Chain

Factory Lead Time 4 Weeks
