LCCF2-14A-E
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 2AWG 76.2mm 17.8mm Tin
PDF
/
Buying Options
Total Price: USD $10.01
Unit Price: USD $10.0056
≥1 USD $10.0056
≥10 USD $9.73368
≥100 USD $9.462816
Inventory: 88
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Weight 30.299999g
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Brown
Gender Female
HTS Code 8536.90.40.00
Depth 17.8mm
Contact Finish Electro-Tin
Wire Gauge 2 AWG
Body Plating Tin
Wire/Cable Gauge 2 AWG
Terminal and Terminal Block Type RING TERMINAL
Safety Approval CSA; UL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 1/4 Stud
Terminal Style Two Stud Holes
Dimensions
Length 76.2mm
Length - Overall 3.000 76.20mm
Width - Outer Edges 0.700 17.78mm
Tab Thickness 0.110 2.79mm
Diameter - Barrel ID 0.360 (9.14mm)
Diameter - Barrel OD 0.550 (13.97mm)
Diameter - Ring ID 0.270 (6.86mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
