LCCF2/0-14B-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (2/0)AWG 90.4mm 24.4mm Tin
PDF
/
Buying Options
Total Price: USD $13.48
Unit Price: USD $13.4816
≥1 USD $13.4816
≥10 USD $13.1164
≥100 USD $12.023
≥500 USD $11.294334
Inventory: 97
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.270 (6.86mm)
Diameter - Barrel OD 0.730 (18.54mm)
Diameter - Barrel ID 0.510 (12.95mm)
Tab Thickness 0.130 3.30mm
Width - Outer Edges 0.960 24.38mm
Length - Overall 3.560 90.42mm
Length 90.424mm
Technical
Terminal Style Two Stud Holes
Stud/Tab Size 1/4 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Safety Approval CSA; UL
Terminal and Terminal Block Type RING TERMINAL
Body Plating Tin
Wire Gauge 2/0 AWG
Contact Finish Electro-Tin
Depth 24.4mm
HTS Code 8536.90.40.00
Color Orange
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
