LCCF1-38D-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 1AWG 93.7mm 19.3mm Tin
PDF
/
Buying Options
Total Price: USD $9.98
Unit Price: USD $9.984525
≥1 USD $9.984525
≥10 USD $9.419367
≥100 USD $8.886184
≥500 USD $8.383197
≥1000 USD $7.90868
Inventory: 7514
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Pink
HTS Code 8536.90.40.00
Depth 19.3mm
Contact Finish Electro-Tin
Wire Gauge 1 AWG
Body Plating Tin
Wire/Cable Gauge 1 AWG
Terminal and Terminal Block Type RING TERMINAL
Safety Approval CSA; UL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 3/8 Stud
Terminal Style Two Stud Holes
Dimensions
Length 93.726mm
Length - Overall 3.690 93.73mm
Width - Outer Edges 0.760 19.30mm
Tab Thickness 0.120 3.05mm
Diameter - Barrel ID 0.390 (9.91mm)
Diameter - Barrel OD 0.590 (14.99mm)
Diameter - Ring ID 0.410 (10.41mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
