LCC8-14AW-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Pan-Lug? ROHS3Compliant 2006 Non-Insulated Terminal Rectangular Connector 8AWG 12.19mm
PDF
/
Buying Options
Total Price: USD $5.59
Unit Price: USD $5.588
≥1 USD $5.588
≥10 USD $5.43752
≥100 USD $4.98476
≥500 USD $4.682638
Inventory: 225
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Weight 498.951607g
Technical
Packaging Bulk
Published 2006
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Red
Gender Female
HTS Code 8536.90.40.00
Depth 12.19mm
Contact Finish Electro-Tin
Wire Gauge 8 AWG
Body Plating Tin
Wire/Cable Gauge 8 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 1/4 Stud
Terminal Style Two Stud Holes
Dimensions
Length 53.34mm
Length - Overall 2.100 53.34mm
Width - Outer Edges 0.480 12.19mm
Tab Thickness 0.070 1.78mm
Diameter - Barrel ID 0.180 (4.57mm)
Diameter - Barrel OD 0.270 (6.86mm)
Diameter - Ring ID 0.270 (6.86mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
