LCC8-10AF-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 8AWG 38.86mm 10.41mm Electro-Tin
PDF
/
Buying Options
Total Price: USD $6.12
Unit Price: USD $6.1248
≥1 USD $6.1248
Inventory: 99
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Red
HTS Code 8536.90.40.00
Contact Finish Electro-Tin
Wire Gauge 8 AWG
Wire/Cable Gauge 8 AWG
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 10 Stud
Terminal Style Two Stud Holes
Dimensions
Width - Outer Edges 0.410 10.41mm
Tab Thickness 0.080 2.03mm
Diameter - Barrel ID 0.180 (4.57mm)
Diameter - Barrel OD 0.270 (6.86mm)
Diameter - Ring ID 0.200 (5.08mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
