LCC8-00-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 8AWG 69.9mm 15.2mm Tin
PDF
/
Buying Options
Total Price: USD $4.52
Unit Price: USD $4.520543
≥1 USD $4.520543
≥10 USD $4.264666
≥100 USD $4.023267
≥500 USD $3.795534
≥1000 USD $3.5807
Inventory: 5260
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Red
HTS Code 8536.90.40.00
Depth 15.2mm
Contact Finish Electro-Tin
Wire Gauge 8 AWG
Body Plating Tin
Wire/Cable Gauge 8 AWG
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Terminal Style No Stud Hole
Terminal Gender FEMALE
Dimensions
Length 69.85mm
Length - Overall 2.750 69.85mm
Width - Outer Edges 0.600 15.24mm
Tab Thickness 0.050 1.27mm
Diameter - Barrel ID 0.180 (4.57mm)
Diameter - Barrel OD 0.270 (6.86mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Alternative Model
