LCC6-14JWF-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Pan-Lug? ROHS3Compliant 2004 Non-Insulated Terminal Rectangular Connector 6AWG 0.220 (5.59mm)
PDF
/
Buying Options
Total Price: USD $7.93
Unit Price: USD $7.926149
≥1 USD $7.926149
≥10 USD $7.477498
≥100 USD $7.054238
≥500 USD $6.654948
≥1000 USD $6.278249
Inventory: 6854
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Blue
HTS Code 8536.90.40.00
Contact Finish Electro-Tin
Wire Gauge 6 AWG
Wire/Cable Gauge 6 AWG
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 1/4 Stud
Terminal Style Two Stud Holes
Dimensions
Width - Outer Edges 0.480 12.19mm
Tab Thickness 0.080 2.03mm
Diameter - Barrel ID 0.220 (5.59mm)
Diameter - Barrel OD 0.310 (7.87mm)
Diameter - Ring ID 0.270 (6.86mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
