LCC6-10AF-L

Panduit Corp
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description Pan-Lug? ROHS3Compliant 2004 Non-Insulated Terminal Rectangular Connector 6AWG 11.7mm
PDF
/
Buying Options
Total Price: USD $9.94
Unit Price: USD $9.9352
≥1 USD $9.9352
≥10 USD $9.6668
≥100 USD $9.3984
≥500 USD $9.13
≥1000 USD $8.861512
≥3000 USD $8.592954
Inventory: 120
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Diameter - Ring ID 0.200 (5.08mm)
Diameter - Barrel OD 0.310 (7.87mm)
Diameter - Barrel ID 0.220 (5.59mm)
Tab Thickness 0.080 2.03mm
Width - Outer Edges 0.460 11.68mm
Length 39.9mm

Technical

Terminal Style Two Stud Holes
Stud/Tab Size 10 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge 6 AWG
Body Plating Tin
Wire Gauge 6 AWG
Contact Finish Electro-Tin
Depth 11.7mm
HTS Code 8536.90.40.00
Color Blue
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2004
Packaging Bulk

Physical

Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Material Copper

Supply Chain

Factory Lead Time 4 Weeks
