LCC500-38DF-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Pan-Lug? ROHS3Compliant 2004 Non-Insulated Terminal Rectangular Connector 0.840 (21.34mm)
PDF
/
Inventory: 2496
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.410 (10.41mm)
Diameter - Barrel OD 1.060 (26.92mm)
Diameter - Barrel ID 0.840 (21.34mm)
Tab Thickness 0.220 5.59mm
Width - Outer Edges 1.540 39.12mm
Technical
Terminal Style Two Stud Holes
Stud/Tab Size 3/8 Stud
Wire Cross Section 323 mm2
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge 500MCM (kcmil)
Contact Finish Electro-Tin
HTS Code 8536.90.40.00
Color Brown
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
