LCC500-00-6

Panduit Corp
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description Lug Terminal (7.7/0)AWG 161.5mm 39.1mm Tin
PDF
/
Buying Options
Total Price: USD $32.3
Unit Price: USD $32.296
≥1 USD $32.296
≥10 USD $31.39576
≥100 USD $28.704456
≥500 USD $27.807446
Inventory: 51
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 4 Weeks

Physical

Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)

Technical

Packaging Bulk
Published 2004
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Brown
HTS Code 8536.90.40.00
Depth 39.1mm
Contact Finish Electro-Tin
Wire Gauge 500MCM (kcmil)
Body Plating Tin
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Terminal Style No Stud Hole
Terminal Gender FEMALE

Dimensions

Length 161.544mm
Length - Overall 6.360 161.54mm
Width - Outer Edges 1.540 39.12mm
Tab Thickness 0.220 5.59mm
Diameter - Barrel ID 0.840 (21.34mm)
Diameter - Barrel OD 1.060 (26.92mm)

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
