LCC4-14BWF-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (3-4)AWG/2AWG 47.5mm 14mm Tin
PDF
/
Inventory: 5548
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.270 (6.86mm)
Diameter - Barrel OD 0.380 (9.65mm)
Diameter - Barrel ID 0.280 (7.11mm)
Tab Thickness 0.090 2.29mm
Width - Outer Edges 0.550 13.97mm
Length 47.5mm
Technical
Terminal Style Two Stud Holes
Stud/Tab Size 1/4 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Body Plating Tin
Wire Gauge (Min) 2 AWG
Wire Gauge (Max) 4 AWG
Wire Gauge 2-4 AWG
Contact Finish Electro-Tin
Depth 14mm
HTS Code 8536.90.40.00
Color Gray
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
