LCC4-12W-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 4AWG 101.9mm 19.1mm Tin
PDF
/
Buying Options
Total Price: USD $13.37
Unit Price: USD $13.3672
≥1 USD $13.3672
≥10 USD $13.00728
≥100 USD $11.92356
≥500 USD $11.200886
Inventory: 124
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.530 (13.46mm)
Diameter - Barrel OD 0.380 (9.65mm)
Diameter - Barrel ID 0.280 (7.11mm)
Tab Thickness 0.070 1.78mm
Width - Outer Edges 0.750 19.05mm
Length - Overall 4.010 101.85mm
Length 101.854mm
Technical
Terminal Gender FEMALE
Terminal Style Two Stud Holes
Stud/Tab Size 1/2 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Wire/Cable Gauge 4 AWG
Body Plating Tin
Wire Gauge (Min) 2 AWG
Wire Gauge (Max) 4 AWG
Wire Gauge 2-4 AWG
Contact Finish Electro-Tin
Depth 19.1mm
HTS Code 8536.90.40.00
Color Gray
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2009
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
