LCC4-10AWH-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (3-4)AWG/2AWG 53.6mm 14mm Tin
PDF
/
Inventory: 9930
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line), 45° Angle
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Gray
HTS Code 8536.90.40.00
Depth 14mm
Contact Finish Electro-Tin
Wire Gauge 2-4 AWG
Wire Gauge (Max) 4 AWG
Wire Gauge (Min) 2 AWG
Body Plating Tin
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Style Two Stud Holes
Stud/Tab Size 10 Stud
Terminal Type Rectangular Tongue
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.200 (5.08mm)
Diameter - Barrel OD 0.380 (9.65mm)
Diameter - Barrel ID 0.280 (7.11mm)
Tab Thickness 0.090 2.29mm
Width - Outer Edges 0.550 13.97mm
Length 53.6mm
