LCC4/0-38WF-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (4/0)AWG 91.2mm 26.9mm Tin
PDF
/
Inventory: 8417
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Purple
HTS Code 8536.90.40.00
Contact Finish Electro-Tin
Wire Gauge 4/0 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Wire Cross Section 107.26 mm2
Stud/Tab Size 3/8 Stud
Terminal Style Two Stud Holes
Dimensions
Width - Outer Edges 1.060 26.92mm
Tab Thickness 0.140 3.56mm
Diameter - Barrel ID 0.570 (14.48mm)
Diameter - Barrel OD 0.710 (18.03mm)
Diameter - Ring ID 0.410 (10.41mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
