LCC3/0-12DWF-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Pan-Lug? ROHS3Compliant 2004 Non-Insulated Terminal Rectangular Connector 24.4mm
PDF
/
Inventory: 9599
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Orange
HTS Code 8536.90.40.00
Depth 24.4mm
Contact Finish Electro-Tin
Wire Gauge 3/0 AWG
Body Plating Tin
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Wire Cross Section 85.05 mm2
Stud/Tab Size 1/2 Stud
Terminal Style Two Stud Holes
Dimensions
Length 75.7mm
Width - Outer Edges 0.960 24.38mm
Tab Thickness 0.130 3.30mm
Diameter - Barrel ID 0.510 (12.95mm)
Diameter - Barrel OD 0.640 (16.26mm)
Diameter - Ring ID 0.530 (13.46mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
