LCC2/0-56DW-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (2/0)AWG 91.7mm 21.6mm Tin
PDF
/
Buying Options
Total Price: USD $9.96
Unit Price: USD $9.9616
≥1 USD $9.9616
≥10 USD $9.69496
Inventory: 50
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.340 (8.64mm)
Diameter - Barrel OD 0.580 (14.73mm)
Diameter - Barrel ID 0.450 (11.43mm)
Tab Thickness 0.130 3.30mm
Width - Outer Edges 0.850 21.59mm
Length - Overall 3.610 91.70mm
Length 91.694mm
Technical
Terminal Style Two Stud Holes
Stud/Tab Size 5/16 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Body Plating Tin
Wire Gauge 2/0 AWG
Contact Finish Electro-Tin
Depth 21.6mm
HTS Code 8536.90.40.00
Color Black
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
