LCC1000-12W-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (10.7/0)AWG 175mm 55.1mm Tin
PDF
/
Buying Options
Total Price: USD $64.05
Unit Price: USD $64.0464
≥1 USD $64.0464
Inventory: 75
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color White
HTS Code 8535.90.80.20
Depth 55.1mm
Contact Finish Electro-Tin
Wire Gauge 1000MCM (kcmil)
Body Plating Tin
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 1/2 Stud
Terminal Style Two Stud Holes
Dimensions
Length 175.006mm
Length - Overall 6.890 175.01mm
Width - Outer Edges 2.170 55.12mm
Tab Thickness 0.320 8.13mm
Diameter - Barrel ID 1.170 (29.72mm)
Diameter - Barrel OD 1.500 (38.10mm)
Diameter - Ring ID 0.530 (13.46mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
